NDI Video Encoder Decoder
>
|
| Place of Origin | Beijing, China |
| Brand Name | TCHD |
| Model Number | TC 310 |
RTMP/RTSP/HTTP/TS independent audio 1080p60 quad band iptv streaming encoder server
TC-310 HDMI encoder is a professional audio and video encoding products, which support 1 channel HDMI video input with embedded audio input and 1 x 3.5MM independent audio interface acquisition, quad streaming H.264 encoded output format,AAC+/AAC++/MP3 audio compression, support TS/HLS/RTSP/FLV/RTMP network protocols, it is easy to install, can add subtitles and logo, and there is no computer hardware compatibility issues.
Product Model | TC-310H |
Video&Audio Input | |
Video Input | 1XHDMI |
Input Resolution | 1920x1080/1680x1056/1280x720/1024x576/850x480/ 720x576/720x540/720x480/720x404/704x576/640x480/ 640x360/608x448/544x480/480x480/480x384/480x360/ 480x320/480x272/480x270/400x320/400x224/352x480/ 352x228/320x256/320x240/320x180/240x180/176x144 |
Audio Input | 1xHDMI Embedded Audio |
Audio Output | 1xAudio Output |
Video Parameters | |
Compression Format | H.264 Baseline Profile |
H.264 Main Profile | |
H.264 High Profile | |
Video Frame Rate | 5-60fp adjustable |
Video Bit rate(kbit) | 32-32000 adjustable |
Audio Parameters | |
Audio input | HDMI/Analog |
Audio Compression | AAC+/AAC++/MP3 |
Audio Frame Rate | 44100/48000 |
Bit rate | 12000-32000 adjustable |
Net Parameters | |
Configuration Management | Web UI for system configuration Firmware up gradable |
Network feature | Ethernet 10/100Mbps RJ45 |
Stream Type | Main and Sub Stream |
Network Protocol | TS/HLS/RTSP/FLV/RTMP |
OSD | |
Diaphaneity | 0-128 adjustable |
Type | Text/Picture/Rolling text |
Area | 4 area can be chosen |
X coordinate | 0-1920 |
Y coordinate | 0-1080 |
Logo | 4 logo available to be uploaded |
General | |
Power | DC 12V, 2A |
Power Consumption | <5W |
Working temperature | -20℃~ - 60℃ |
Working humidity | <90% |
Dimensions (mm) | 107mm x 80mm x 30mm |
