Digital Video Converter
>
|
| Place of Origin | Beijing, China |
| Brand Name | TCHD |
| Model Number | Multi2SDI |
Simple innovative productsaspect ratio video converternew inventions in china
TCHD Multi to SDI video converter is a high-quality, high-performance video signal conversion product. It Supports Support 3 BNC(YPbPr, CVBS) + 1 DVI(HDMI/DVI /VGA) inputs and 2 channels SDI outputs.Unlike the traditional converter products in current market, our Multi to SDI Converter which built in a professional image conversion processing chip, support the user-adjustable to set the saturation / brightness / contrast, and through automatic scaling and frame rate conversion, any input format video signal can be converted to a standard SD/HD/3G-SDI , compatible with all common HDMI, VGA and CVBS signals.
|
Description |
Convert from DVI-D/VGA or Component/S-Video/Composite input to 3G/HD/SD-SDI output |
|
Feature |
Buit-in up/down conversion engine Video enhancement with anti-aliasing and 3D deinterlacer Simultaneous 2xSDI output Hot-keys for video mode and device configrations Mini-USB port for configurations and software upgrade |
|
Input |
DVHx1(Support DVI-D and VGA) BNHx3 for component/S-Video/Composite 3.5mm Phone jack for analog audio |
|
Output |
Up/Down Converted SDIx2 |
|
Supported Video Input Format |
Composite/SVideo Component DVI/VGA |
|
Supported Video Output Format |
SDI |
|
Audio Input Format |
HDMI/SDl:Up to 8 channels,24bit,48KHz |
|
Audio Output Format |
Up to 8 channels, 24bit, 48KHz |
|
Plug & Play |
YES |
|
DC In |
7.5V-15V |
